24VAC Non-Reversing Magnetic Contactor 3P 135A NEMA 4 - CN15NN3T

24VAC Non-Reversing Magnetic Contactor 3P 135A NEMA 4 - CN15NN3T

Eaton
SKU:
CN15NN3T
|
UPC:
782113701059
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
NEMA Magnetic Contactor, Auxiliary Contact Form 1NO, NEMA Enclosure Rating No Enclosure, NEMA Size 4, Coil Voltage 24V AC, Number of Poles 3, Full Load Current - Inductive 135 A, Reversing Capability Non-Reversing, Overall Height 9.11 in, Overall Width 7.05 in, Terminal Connection Type Screw Terminals, Frame Size N, Mounting Style Panel, Series Freedom, Number of Auxillary Contacts 1, Contactor Style NEMA, Horsepower @ Three Phase - 240V AC 50 hp, Horsepower @ Three Phase - 480V AC 100 hp
Additional Information
Country of Origin:
Dominican Republic
Item:
Magnetic Contactor
Full Load Amps:
135 A
Action:
Non-Reversing
Number of Poles:
3
NEMA Contactor Size:
4
Coil Volts:
24V AC
Reversing:
No
Height:
9.3 in
HP @ 3 Phase - 208V:
40 hp
Width:
9.31 in
HP @ 3 Phase - 575V:
100 hp
Depth:
9.5 in
HP @ 3 Phase - 240V:
50 hp
HP @ 3 Phase - 480V:
100 hp
Enclosure NEMA Rating:
No Enclosure
Frame / Series / Class / Code:
Series Freedom, Code B1, Frame 180mm
NEMA Size:
4
Auxiliary Contact Form:
1NO
Hz:
50/60
Standards:
BS, CSA LR353ISO 9000, UL E1491, VDE
Series:
Freedom
Product Height:
9.11 in
Amperage Rating:
135A
Certifications:
CSA Certified
Phase:
Three
Full load current range:
208 V at 60 Hz
Size:
4
Horsepower:
40 hp at 208 V, 50 hp at 240 V, 100 hp at 480/600 V
Product Length/Depth:
7.25 in
Product Width:
7.05 in
Includes Auxiliary Contacts:
Yes
Mounting Postion:
Horizontal, Vertical
Horsepower @ Three Phase - 600V AC:
100 hp
Overall Height:
9.11 in
Number of Auxillary Contacts:
1
Mounting Hole Distance - Width:
6 in
Overall Depth:
7.25 in
Maximum Voltage Rating:
600V AC
Full Load Current - Inductive:
135 A
Contactor Style:
NEMA
Frequency:
50/60 Hz
Mechanical Operating Durability:
5,000,000
Embedded Surge Suppressor:
No
Frame Size:
N
Terminal Connection Type:
Screw Terminals
Reversing Capability:
Non-Reversing
Mounting Hole Diameter:
0.25 in
Mounting Style:
Panel
Horsepower @ Three Phase - 240V AC:
50 hp
NEMA Enclosure Rating:
No Enclosure
Overall Width:
7.05 in
Mounting Hole Distance - Height:
6.5 in
Coil Voltage:
24V AC
Minimum Operating Temperature:
-4 Degrees F
Horsepower @ Three Phase - 208V AC:
40 hp
Response Time:
28 msec
Resistance Properties:
Impact Resistant, Temperature Resistant
NEMA Enclosure Material:
Not Applicable
Electrical Operating Durability:
70,000 (AC-4), 800,000 (AC-3)
Horsepower @ Three Phase - 480V AC:
100 hp
Maximum Operating Temperature:
149 Degrees F
Package Quantity:
1
