240VAC Non-Reversing Magnetic Contactor 3P 60A NEMA 2-1/2 - 40GP32AA

240VAC Non-Reversing Magnetic Contactor 3P 60A NEMA 2-1/2 - 40GP32AA

Siemens
SKU:
40GP32AA
|
UPC:
783087068377
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
NEMA Magnetic Contactor, Auxiliary Contact Form 1NO, NEMA Enclosure Rating No Enclosure, NEMA Size 2-1/2, Coil Voltage 110-120/220-240V AC, Number of Poles 3, Full Load Current - Inductive 60 A, Full Load Current - Resistive Not Rated, Reversing Capability Non-Reversing, Overall Height 4.88 in, Overall Width 4.25 in, Auxiliary Contact Module Capacity 8, Terminal Connection Type Screw Terminals, Mounting Style Surface, Series 40, Number of Auxillary Contacts 1, Contactor Style NEMA
Additional Information
Country of Origin:
Mexico
Item:
Magnetic Contactor
Action:
Non-Reversing
Full Load Amps:
60 A
Number of Poles:
3
Coil Volts:
240V AC
NEMA Contactor Size:
2-1/2
Reversing:
No
Height:
3.94 in
HP @ 3 Phase - 208V:
15 hp
Width:
4.88 in
Depth:
4.25 in
HP @ 3 Phase - 575V:
30 hp
HP @ 3 Phase - 240V:
20 hp
Enclosure NEMA Rating:
No Enclosure
HP @ 3 Phase - 480V:
30 hp
NEMA Size:
2-1/2
Auxiliary Contact Form:
1NO
Standards:
REACH Art 33
Hz:
60
Frame / Series / Class / Code:
Class 40
Series:
40
Number of Normally Open Main Contacts:
3
Coil Voltage:
110-120/220-240V AC
Embedded Surge Suppressor:
No
Contactor Style:
NEMA
Phase:
Three
Maximum Voltage Rating:
600V AC
Auxiliary Contact Module Capacity:
8
Includes Auxiliary Contacts:
Yes
Frequency:
60 Hz
Overall Height:
4.88 in
Horsepower @ Three Phase - 480V AC:
30 hp
Reversing Capability:
Non-Reversing
Full Load Current - Inductive:
60 A
NEMA Enclosure Rating:
No Enclosure
Minimum Operating Temperature:
-4 Degrees F
Terminal Connection Type:
Screw Terminals
Mechanical Operating Durability:
10,000,000
Horsepower @ Three Phase - 208V AC:
15 hp
Maximum Operating Temperature:
104 Degrees F
Full Load Current - Resistive:
Not Rated
NEMA Enclosure Material:
Not Applicable
Overall Width:
4.25 in
Mounting Style:
Surface
Overall Depth:
4 in
Number of Auxillary Contacts:
1
Number of Normally Closed Main Contacts:
0
Horsepower @ Three Phase - 600V AC:
30 hp
Response Time:
10 to 24 msec (OFF-Delay Time), 19 to 29 msec (ON-Delay Time)
Mounting Postion:
Vertical
Horsepower @ Three Phase - 240V AC:
20 hp
Package Quantity:
1
