24" x 24" 1 HP 41.0 gal. Simplex Sewage System 115V - P382PRG101SD-2

24" x 24" 1 HP 41.0 gal. Simplex Sewage System 115V - P382PRG101SD-2

Liberty Pumps
SKU:
P382PRG101SD-2
|
UPC:
671812136579
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Sewage Ejector System, HP 1, Number of Pumps 1, Rated Voltage 115V AC, Hz 60 Hz, Phase - Pumps 1, Switch Actuation Tether Float, Switch Electrical Connection Integral, Off Point 4 1/2 in, On Point 11 1/2 in, Pump Body Material Polyethylene, Basin Material Polyethylene, Flow Rate @ 5 Ft. of Head 44 gpm, Flow Rate @ 10 Ft. of Head 42 gpm, Flow Rate @ 15 Ft. of Head 39 gpm, Flow Rate @ 20 Ft. of Head 37 gpm, Max. Diameter Solids 2 in, Cord Length 20 ft, Max. Liquid Temp. 140 Degrees F
Additional Information
Country of Origin:
United States
Switch Type:
Mechanical Float
Tank Width:
25";Motor Type=Start Capacitor / Run Capacitor"
GPM of Water @ 25 Ft. of Head:
32
Height:
24";Base Material=Polyethylene"
Impeller Material:
Cast Iron
Voltage - Pumps:
115VAC
On Point:
11 1/2 in
Diameter:
24";Thermal Protection=yes"
Basin Capacity:
41 gal
Housing Material:
Polyethylene
Features:
Compact System 1 HP Grinder with V-Slice(R) Cutter Technology
GPM of Water @ 5 Ft. of Head:
44
Item - Sump/Sewage Pump Systems:
Simplex Sewage System
Pump HP:
1
Cord Length - Pumps:
20 ft.
Tank Length:
25";GPM of Water @ 50 Ft. of Head=1"
Motor RPM:
1725
Bearing Type:
Ball
Input Phase AC:
1
Cord Length:
20 ft
Handle:
yes
Shaft Seal:
Silicon Carbide
Max. Head - Pumps:
50 ft.
GPM of Water @ 35 Ft. of Head:
22
Inlet:
4 in
Includes:
Heavy Duty Submersible Pump, Pre-Assembled Basin with Cover and Controls
Phase:
1
Cord Size:
16-3
Amps - Pumps:
12.00
Voltage:
115V
GPM of Water @ 10 Ft. of Head:
42
Manufacturers Warranty Length:
3 yr
GPM of Water @ 45 Ft. of Head:
8
Impeller Material - Pumps:
Cast Iron
Application:
Sewage Transfer
Agency Compliance:
CSA Certified
Cover Material:
Polyethylene
Basin Material:
Polyethylene
GPM of Water @ 15 Ft. of Head:
39
Check Valve:
No
Hz:
60 Hz
Basin Height:
24 in
Outlet:
2";Pump Body Material=Polyethylene"
Width:
25";Switch Type - Pumps=Float"
Basin Dia.:
24 in
Length:
25";Item=Sewage Ejector System"
Max. Liquid Temp.:
140 Degrees F
HP:
1
GPM of Water @ 20 Ft. of Head:
37
Amps:
12.0
GPM of Water @ 40 Ft. of Head:
16
Min. Sump Pit Dia.:
18";Pump RPM=1725"
Duty:
Continuous
Discharge NPT:
2 F"
GPM of Water @ 30 Ft. of Head:
27
Max. Head:
50 ft
Max Head - Pumps:
50 ft.
Off Point:
4 1/2 in
Max. Diameter Solids:
2 in
RPM:
1,725 RPM
Pump Discharge Diameter:
2 in
Rated Voltage:
115V AC
Inlet Gender:
Female
Phase - Pumps:
1
Flow Rate @ 15 Ft. of Head:
39 gpm
Flow Rate @ 5 Ft. of Head:
44 gpm
Flow Rate @ 20 Ft. of Head:
37 gpm
Flow Rate @ 10 Ft. of Head:
42 gpm
Vent Size:
2 in
Switch Electrical Connection:
Integral
Duty Cycle:
Continuous
Alarm Included:
No
Number of Pumps:
1
Switch Actuation:
Tether Float
Inlet Dia.:
4 in
Package Quantity:
1
