22-18 AWG Nylon Ring Terminal #6 Stud PK100 - PN18-6R-C

22-18 AWG Nylon Ring Terminal #6 Stud PK100 - PN18-6R-C

Panduit
SKU:
PN18-6R-C
|
UPC:
74983800025
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Ring Terminal, Insulation Color Red, Insulation Coverage Partial Coverage, Insulation Material Nylon, Maximum Operating Temperature 221 Degrees F, Maximum Voltage 600 V, Minimum Wire Size 22 AWG, Maximum Wire Size 18 AWG, Termination Style Crimp, Tongue Width 0.25 in, Contact Finish Tin, Contact Material Copper, UL 94 Flammability Rating HB, Standards CSA C22.2 No. 65, UL 486A, UL 486B, Barrel Inside Diameter 0.15 in, Barrel Style Insulation Grip
Additional Information
Country of Origin:
Mexico
Wire Range:
22 to 18 AWG
Insulation Type:
Nylon
Stud Size:
#6
Insulation Color:
Red
Max. Voltage:
600 V
Connection Material:
Copper
Connection Type:
Crimp
Standards:
CSA C22.2 No. 65, UL 486A, UL 486B
Seam:
Grip Sleeved
Item:
Ring Terminal
Terminal Connection:
Crimp
Overall Length:
0.79 in
Tongue Width - Wire Connector:
0.25 in
Max. Temp.:
221 Degrees F
Green Environmental Attribute:
Does Not Contain PVC
Features:
Flame Retardant
Terminal Type:
Ring Tongue
For Use With:
CT-100, CT-1550, CT-1551, CT-2300/ST (CD-550), CT-2500/L (CT-2550CH), UP14ZLW (CD-550)
Length:
0.8";Width=0.3""
Insulation Material:
Nylon
Barrel Style:
Insulation Grip
Tongue Thickness:
0.03 in
Compatible Manufacturer Model Number:
CT-100, CT-1550, CT-1551, CT-2300/ST, CT-2500/L, UP14ZLW
Maximum Voltage:
600 V
Minimum Operating Temperature:
221 Degrees F
Barrel Inside Diameter:
0.15 in
Maximum Operating Temperature:
221 Degrees F
Insulation Coverage:
Partial Coverage
Contact Material:
Copper
Maximum Wire Size:
18 AWG
Termination Style:
Crimp
UL 94 Flammability Rating:
HB
Terminal Shape:
Ring Terminal
Special Features:
Internal Barrel Serrations Assure Good Wire Contact and Maximum Tensile Strength, Metal Insulation Grip Sleeve Crimps to Wire Insulation, Providing Protection to the Crimp Joint During High Vibration Applications, Ring Tongue Design Assures a Secure
Seam Style:
Grip Sleeved
Hole Diameter:
0.15 in
Minimum Wire Size:
22 AWG
Strip Length:
1/4 in
Contact Finish:
Tin
Tongue Width:
0.25 in
Insulation Dia:
0.145 in
Product Color:
Red
Product Name:
Terminal Connector
Connector Type:
Ring Terminal
Connector Details:
1 x Ring Terminal
Environmentally Friendly:
Yes
Product Material:
Copper
Connector Plating:
Tin
Product Type:
Terminal Connector
Base Material:
Copper
Wire Strip Length (In.):
11871
Maximum Voltage (V):
600
Overall Width (mm):
6.4
Maximum Wire Insulation Diameter (mm):
3.68
Standards Met:
cULus Listed 587H E52164, CSA Certified LR31212, Military QPL AS7928 (MS25036-102)
Overall Length (In.):
0.79
Maximum Metric Conductor Size (mm²):
1.5
Maximum Voltage (kV):
0.6
Tongue Thickness (In.):
0.03
Tongue Width (In.):
0.25
Packaging Type:
Bottle
Maximum Operating Temperature (°C):
105
Maximum Wire Size (AWG):
#18
Stud Hole Size (In.):
#6
Maximum Wire Insulation Diameter (In.):
0.145
Maximum Operating Temperature (°F):
221
Stud Hole Size (mm):
3.5
Finish/Coating:
Tin-Plated
Tongue Thickness (mm):
0.8
Barrel Type:
Grip Sleeve
Color Code:
Red
Overall Width (In.):
0.25
Sub Brand:
Pan-Term®
Overall Length (mm):
20.1
Wire Strip Length (mm):
5.6
Minimum Copper Conductor Size (AWG):
#22
Minimum Metric Conductor Size (mm²):
0.5
Maximum Copper Conductor Size (AWG):
#18
Flammability Rating:
UL94-HB
Tongue Width (mm):
6.4
Minimum Wire Size (AWG):
#22
Maximum Operating Temperature (°C):
105
Maximum Operating Temperature (°F):
221
Minimum Metric Conductor Size (mm²):
0.5
Maximum Metric Conductor Size (mm²):
1.5
Package Quantity:
100
