22-18 AWG Nylon Fork Terminal #6 Stud PK100 - PN18-6F-C

22-18 AWG Nylon Fork Terminal #6 Stud PK100 - PN18-6F-C

Panduit
SKU:
PN18-6F-C
|
UPC:
74983803002
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Fork Terminal, Contact Finish Tin, Contact Material Copper, Insulation Color Red, Insulation Material Nylon, Maximum Operating Temperature 221 Degrees F, Maximum Voltage 600 V, Maximum Wire Size 18 AWG, Stud Size #6, Termination Style Crimp, Tongue Length 0.39 in, Seam Style Butted, Standards CSA Certified, UL 587-H, UL Listed, Barrel Length 0.39 in, Barrel Style Insulation Grip, Compatible Grainger Part Number 376T39, Compatible Manufacturer Model Number CT-100, CT-160, CT-260
Additional Information
Country of Origin:
Mexico
Wire Range:
22 to 18 AWG
Insulation Type:
Nylon
Stud Size:
#6
Insulation Color:
Red
Max. Temp.:
221 Degrees F
Max. Voltage:
600 V
Terminal Connection:
Crimp
Seam:
Grip Sleeved
Tongue Width - Wire Connector:
0.3 in
Terminal Type:
Standard
Connection Type:
Crimp
Standards:
CSA Certified, UL 587-H, UL Listed
Item:
Fork Terminal
Overall Length:
0.78 in
Connection Material:
Copper
Features:
Barrel of Terminal Internally Beveled to Provide, Fork Design Provides for Fast and Easy Installation, Internal Barrel Serrations Assure Good Wire Contact and Maximum Tensile Strength, Without The Need to Remove Fastener
Length:
0.8";For Use With=CT-100, CT-1550, CT-1551, CT-2300/ST (CD-550), CT-2500/L (CT-2550CH), UP14ZLW (CD-550)"
Width:
0.3";Maximum Operating Temperature=221 Degrees F"
Contact Material:
Copper
Tongue Length:
0.00 - 0.50 inches
Terminal Shape:
Standard Fork
Barrel Style:
Insulation Grip
Compatible Manufacturer Model Number:
CT-100, CT-160, CT-260
Minimum Wire Size:
22 AWG
Maximum Wire Size:
18 AWG
Maximum Voltage:
600 V
Barrel Length:
0.39 in
Special Features:
Fork Design Provides for Fast and Easy Installation Without the Need to Remove Fastener, Internal Barrel Serrations Assure Good Wire Contact and Maximum Tensile Strength, Metal Insulation Grip Sleeve Crimps to Wire Insulation, Providing Protection to
Insulation Material:
Nylon
Compatible with Series:
CT
Strip Length:
1/4 in
Termination Style:
Crimp
Seam Style:
Butted
Tongue Thickness:
0.03 in
Contact Finish:
Tin
Compatible with Product Type:
Crimp Tool
Tongue Width:
0.3 in
Insulation Dia:
0.145 in
Connector Details:
1 x Fork Terminal
Product Color:
Red
Connector Type:
Fork Terminal
Environmentally Friendly:
Yes
Product Type:
Terminal Connector
Product Material:
Nylon
Diameter:
0.2";Connector Plating=Tin"
Product Name:
Terminal Connector
Color Code:
Red
Overall Length (In.):
0.78
Overall Length (mm):
19.8
Packaging Type:
Bottle
Tongue Thickness (mm):
0.8
Maximum Copper Conductor Size (AWG SOL):
#18
Tongue Thickness (In.):
0.03
Sub Brand:
Pan-Term®
Maximum Wire Size (AWG):
#18
Flammability Rating:
UL94-HB
Maximum Wire Insulation Diameter (In.):
0.145
Maximum Operating Temperature (°C):
105
Minimum Wire Size (AWG):
#22
Wire Strip Length (mm):
5.6
Tongue Length (In.):
0.39
Maximum Copper Conductor Size (AWG):
#18
Stud Hole Size (In.):
#6
Minimum Metric Conductor Size (mm²):
0.5
Finish/Coating:
Tin-Plated
Tongue Width (mm):
7.6
Overall Width (mm):
7.6
Minimum Copper Conductor Size (AWG):
#22
Overall Width (In.):
0.3
Maximum Voltage (kV):
0.6
Maximum Wire Insulation Diameter (mm):
3.68
Stud Hole Size (mm):
3.5
Tongue Width (In.):
0.3
Fork Type:
Standard
Wire Strip Length (In.):
11871
Maximum Metric Conductor Size (mm²):
1
Maximum Voltage (V):
600
Base Material:
Copper
Barrel Length (In.):
0.39
Barrel Type:
Grip Sleeve
Tongue Length (mm):
9.9
Minimum Copper Conductor Size (AWG SOL):
#22
Maximum Copper Conductor Size (AWG STR):
#18
Barrel Length (mm):
9.9
Maximum Operating Temperature (°F):
221
Standards Met:
UL Listed 587H E52164; CSA Certified LR31212
Minimum Copper Conductor Size (AWG STR):
#22
Seam Type:
Butted
Maximum Operating Temperature (°C):
105
Maximum Operating Temperature (°F):
221
Maximum Metric Conductor Size (mm²):
1
Minimum Metric Conductor Size (mm²):
0.5
Package Quantity:
100
