20A Locking Receptacle 4P 5W 120/208VAC L21-20R GY - HBL2510SR

20A Locking Receptacle 4P 5W 120/208VAC L21-20R GY - HBL2510SR

Hubbell
SKU:
HBL2510SR
|
UPC:
783585234984
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Locking Receptacle, Connection Orientation Straight, Current Rating 20 A, Flange Type Non-Flanged, Housing Color Gray, Housing Material Valox, Mount Type Surface, NEMA Enclosure Rating 1, NEMA Receptacle Configuration L21-20R, Number of Gangs 1, Number of Poles 4, Number of Wires 5, Phase Three, Polarized Yes, Shrouded Yes, Voltage Rating 120/208V AC, Wire Connection Type Screw Terminals, Wiring Style Standard, AFCI No, Contact Material Brass, Cover Type No Cover, Flange Diameter Not Applicable
Additional Information
Country of Origin:
United States
Item:
Locking Receptacle
NEMA Configuration:
L21-20
Voltage:
120/208V AC
Amps:
20
Color:
Gray
Number of Poles:
4
Number of Wires:
5
Phase:
Three
Shrouded / Non-Shrouded:
Shrouded
Wiring Style:
Standard
Special Features:
Corrosion resistant
Material:
Impact Modified PBT
Grade:
Industrial
NEMA Rating:
12, 4X
HP:
2.0
Mounting Type:
Surface Mount
Standards:
CSA Certified C22.2 No. 42, Federal Specification W-C-596, UL 498
IP Rating:
IP20
Flange Diameter:
Not Applicable
AFCI:
No
UL 94 Flammability Rating:
V-2
Housing Color:
Gray
Shrouded:
Yes
Minimum Wire Size:
16 AWG
For Location:
Indoor
Flange Width:
Not Applicable
Voltage Rating:
120/208V AC
Cover Type:
No Cover
Flange Type:
Non-Flanged
Mount Type:
Surface
For Environment:
Dry
Minimum Operating Temperature:
-40 Degrees C
Wire Connection Type:
Screw Terminals
Number of Gangs:
1
Contact Material:
Brass
NEMA Receptacle Configuration:
L21-20R
Current Rating:
20 A
Horsepower Rating:
2 hp
Flange Height:
Not Applicable
Housing Material:
Valox
Polarized:
Yes
Maximum Wire Size:
8 AWG
Connection Orientation:
Straight
Market:
Industrial
NEMA Enclosure Rating:
1
Grounding:
Grounded
Resistance Properties:
Corrosion Resistant, Impact Resistant
Maximum Operating Temperature:
75 Degrees C
Flange Material:
Gray Valox 357U
Weight (Lbs.):
0.5
Operating Temp.:
Maximum Continuous 75A Deg C; Minimum -40A Deg C (w/o impact)
Temp. Rise:
Max 30C temperature rise at full rated current after 50 cycles of overload at 150% of rated current at a power factor of .75.
Terminal Designations:
Terminals identified in accordance with UL 498 (X, Y, Z, White, Green)
Spring Material:
.031 Brass"
Lock Type:
Twist-lock
Flammability:
V2 or better per UL94/CSA 22.2 No.0.17
Wire Size:
#14 to #8 AWG Copper Only
Package Quantity:
1
