20/10A Twist-Lock Connector 4P 5W 250/600VAC BK/WT - HBL3523C

20/10A Twist-Lock Connector 4P 5W 250/600VAC BK/WT - HBL3523C

Hubbell
SKU:
HBL3523C
|
UPC:
783585039923
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Locking Connector, Connection Orientation Straight, Current Rating 20/10 A, Housing Color Black, White, Housing Material Nylon, IP Rating IP20, NEMA Receptacle Configuration Non-NEMA, Number of Poles 4, Number of Wires 5, Phase Three, Resistance Properties Chemical Resistant, Impact Resistant, Shrouded No, Voltage Rating 250/600V AC, Wire Connection Type Screw Terminals, Wiring Style Standard, Cap Type No Cap or Cover, Contact Material Brass, For Maximum Cable Diameter 1.15 in
Additional Information
Country of Origin:
United States
Item:
Locking Connector
Amps - Plugs and Receptacles:
20/10
NEMA Plug Configuration - Plugs and Receptacles:
20A, Non-NEMA
Voltage:
250/600VAC
NEMA Configuration:
Non-NEMA
Number of Poles:
4
Number of Wires:
5
Wiring Style:
Standard
Color:
Black/White
Grade - Plugs and Receptacles:
Industrial
Shrouded / Non-Shrouded:
Non-Shrouded
Material:
Nylon
Standards:
CSA Certified C22.2 No. 42, Federal Specification W-C-596, UL 498
Item - Plugs and Receptacles:
Locking Connector
IP Rating:
IP20
Cord Size:
0.350 in to 1.150 in
Amps:
20/10
Antimicrobial:
No
Color - Plugs and Receptacles:
Black/White
Corrosion Resistant:
No
Power Indicator:
No
Phase:
Three
Grade:
Industrial/Commercial
Voltage - Plugs and Receptacles:
250/600V AC
Special Features:
Terminals identified in accordance with UL 498 (X, Y, Z, White, Green)
Body Material:
Natural White Nylon
Shrouded:
No
For Location:
Indoor
Contact Material:
Brass
For Minimum Cable Diameter:
0.35 in
Housing Material:
Nylon
Midget Locking:
No
Maximum Wire Size:
8 AWG
Wire Connection Type:
Screw Terminals
Housing Color:
Black, White
Power Indicating Light:
No
For Maximum Cable Diameter:
1.15 in
Maximum Operating Temperature:
75 Degrees C
Current Rating:
20/10 A
NEMA Receptacle Configuration:
Non-NEMA
Connection Orientation:
Straight
For Environment:
Dry
Resistance Properties:
Chemical Resistant, Impact Resistant
UL 94 Flammability Rating:
HB
Grounding:
Grounded
Market:
Industrial
Cap Type:
No Cap or Cover
Minimum Wire Size:
16 AWG
Outside Diameter:
2.33 in
Minimum Operating Temperature:
-40 Degrees C
Overall Length:
2.33 in
Voltage Rating:
250/600V AC
Type:
Connector Body
Temp. Rise:
Max 30C temperature rise at full rated current after 50 cycles of overload at 150% of rated current at a power factor of .75.
Cord Dia. Range:
.350-1.150" (9-29)"
Flame Resistant:
HB or better per UL 94 or CSA 22.2 No. 0.6
Weight:
0.45
Dielectric Strength:
Withstands 2,000V minimum
Dimensions:
2.33 in x 2.33 in x 3.86 in
Temperature Rating:
Maximum Continuous
Material - Mounting Hardware:
Cord Mounted
Cable Range:
0.350 - 1.150 in
Voltage Rating Description:
250/600 VAC
Environmental Conditions:
Indoor Dry Unless Protected By Additional Means
Display Size:
Standard
Wire Size:
#16 AWG to #8 AWG
Cord Range:
0.350-1.150" (9-29)"
Connectivity:
Pressure Terminal Screws
Industry Standard(s):
Certified to CSA C22.2 No.42 Fed.Spec. W-C-596 Listed to UL 498
Amperage Rating:
20/10 A
Insulation:
Insulated Body
Width:
2.33 in
Operating Temperature:
Maximum continuous 75°C and minimum -40°C without Impact
Current / Amperage Rating:
20/10 A
Item Type:
20A Insulgrip® Connector
Height:
3.86 in
Nema Rating:
Non-NEMA
Length:
2.33 in
Application:
Heavy Duty Industrial
Performance:
Electrical - Current Interrupting - Certified for current interrupting at full rated current Electrical - Dielectric Voltage - Withstands 2,000V minimum Environmental - Flammability - HB or better per UL94 or CSA 22.2 No. 0.6 Environmental - Operatin
OEM Brand Name:
Hubbell Wiring Device-Kellems
Package Quantity:
1
