10 in Backdraft Damper / Wall Shutter, Front Flange - 3HHN4

10 in Backdraft Damper / Wall Shutter, Front Flange - 3HHN4

Dayton
SKU:
3HHN4
|
UPC:
190735289600
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
13 In.H-W 5 1/4 In.L Aluminum Backdraft Damper, Damper Application Backdraft, For Nominal Duct Diameter Not Applicable, Frame Material Aluminum, Number of Panels 1, Maximum Air Velocity 2500 fpm, Overall Height 13 in, Rough Opening Diameter 10 1/2 in, Rough Opening Shape Square, Fits Fan Diameter 10 in, For Duct Shape Not Applicable, Free Area 0.6 sq ft, Overall Width 13 in, Frame Material Thickness 0.8 in, Overall Length 5 1/4 in, Connection Type Not Applicable, Frame Depth 3 in
Additional Information
Country of Origin:
United States
Item:
13H-W 5 1/4"L Aluminum Backdraft Damper"
Shutter Mounting Position:
Vertical
Shutter Mounting Location:
Wall
Shutter Construction Material:
Extruded Aluminum Frame and Galvanized Tie Rods
Shutter Free Area:
0.645 sq ft
Shutter Opening Required:
10-1/2 in x 10-1/2 in
Shutter Overall Size:
13 in x 13 in
Fits Fan Dia.:
10 in
Blade Material:
Aluminum
Max. Velocity:
2500 FPM
Frame Opening A:
10 in
Open Depth:
5 3/4 in
Shutter Overall Square:
13 x 13""
Frame Depth:
3 in
Number of Panels:
1
Mounting Hole Size:
Prepunched
Frame Opening B:
10 in
Flange Width:
1 1/2 in
Shutter Item:
Backdraft Damper / Wall Shutter, Front Flange
For Use With:
Vertical Mounted Exhaust Fans
Includes:
Prepunched Mounting Holes; Felt edged Counterbalanced Louvers; Weep Holes In Frame Bottom
Mounting Position:
Vertical
Free Area:
0.6 sq ft
Maximum Air Velocity:
2500 fpm
Closure Type:
Gravity
Frame Material Thickness:
0.8 in
For Nominal Duct Diameter:
Not Applicable
Connection Type:
Not Applicable
Damper Type:
Static
Damper Finish:
Mill Finish
Tie-Rod Material:
Galvanized Steel Frame and Tie Rods
Counterbalanced:
Yes
Mounting Hole Diameter:
1/4 in
Rough Opening Length:
10 1/2 in
Single Acting/Double Acting:
Single Acting
Seal Material:
Not Applicable
Opening Type:
Gravity
Closure Velocity Rating:
2,500 fpm
Minimum Ambient Temperature:
-40 Degrees F
Frame Material:
Aluminum
Series:
EASR
Blade Type:
Flat Blade
Rough Opening Diameter:
10 1/2 in
Frame Opening Height:
10 in
Rough Opening Shape:
Square
Fusible Link Temperature:
Not Applicable
Overall Height:
13 in
Airflow Direction:
Horizontal
Flange Type:
Front Flange
Switch Action:
Normally Closed
Blade Material Thickness:
26 ga
For Fuel Type:
Not Applicable
For Duct Shape:
Not Applicable
Pressure Drop @ 1000 fpm (AMCA 5.2):
Not Applicable
Blade Orientation:
Parallel Blades
Frame Less Flange:
10
Rough Opening Width:
10.5 in
Maximum Ambient Temperature:
180 Degrees F
ACMA Leakage Class:
Not Applicable
Damper Application:
Backdraft
Maximum Pressure:
1 in wc
Bushing Material:
Stainless Steel
Blade Seal Material:
Felt
Overall Diameter:
13 in
Overall Width:
13 in
Overall Length:
5 1/4 in
Fits Fan Diameter:
10 in
Frame Opening Width:
10 in
Package Quantity:
1
