1/2" Threaded Dual Check Valve - LF7RU2-2

1/2" Threaded Dual Check Valve - LF7RU2-2

Watts
SKU:
LF7RU2-2
|
UPC:
98268825176
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Dual Check Valve, Size 1/2 In., Body Material Brass, Max. Temp. 180 Degrees F, Width 1 7/8 in, Length 3 5/8 in, Standards ANSI, ASSE 1024, Compliance ASSE 1024, NSF
Additional Information
Country of Origin:
United States
Pipe Size:
1/2";Connection Type=FNPT x FNPT"
Connection:
FNPT x FNPT
Body Material:
Lead Free Brass
Seal Material - Check Valves:
EPDM
Body Material - Valves:
Cast Copper Alloy
Max. Temp. - Valves:
180 Degrees F
Length:
3 5/8 in
Max. Water Pressure - Valves:
150 psi
Cap to Inlet Center:
1 1/2 in
Spring Material - Check Valves:
Stainless Steel
Seat Material - Check Valves:
Composite
Max. Water Pressure:
150 psi
Mounting Position:
Vertical or Horizontal
Mounting Orientation - Check Valves:
Horizontal, Vertical
Overall Height:
3 5/8 in
Max. Pressure:
150 psi
Spring Material:
Stainless Steel
Pipe or Tube Size - Check Valves:
1/2 in
Max. Steam Pressure - Valves:
Not Rated
Flow Design:
Dual
Connection Type - Check Valves:
FNPT x FNPT
Standards:
ASSE 1024, NSF
Mechanism and Body Design:
Inline
Width:
1 7/8 in
Item:
Dual Check Valve
Application - Valves:
General Purpose
Seal Material:
EPDM
Item - Check Valves:
Check Valve
Flow:
15.5 gpm
Compliance:
ASSE 1024, NSF
Material of Construction:
Cast Copper Alloy
Overall Length:
3.63 in
Seat Material:
EPDM
Pipe or Tube Size:
1/2 in
Mounting Orientation:
Horizontal, Vertical
Maximum Pressure - Operating:
150 psi
Hazard Protection Level:
Low Health Hazard
Operating Temperature - Minimum:
33 Degrees F
Nominal Valve Size:
1/2 in
Maximum Pressure - Steam:
Not Rated
Connection Size - Side 1:
1/2 in
Connection Size - Side 2:
1/2 in
Connection Type - Side 1:
NPT
Check Mechanism Material:
Plastic
Manufacturer Warranty:
1 yr
Connection Type - Side 2:
NPT
Connection Gender - Side 2:
Female
Overall Width:
1.88 in
Operating Temperature - Maximum:
180 Degrees F
Connection Gender - Side 1:
Female
For Media:
Water
Package Quantity:
1
